Authentication: AWS

Use dsv config auth-provider search -e yaml to see all of your current authentication providers.

Initially, the only authentication provider is Thycotic One, similar to this:

Copy
created: "2019-11-11T20:29:20Z"
createdBy: users:thy-one:admin@company.com
id: xxxxxxxxxxxxxxxxxxxx
lastModified: "2020-05-18T03:58:15Z"
lastModifiedBy: users:thy-one:admin@company.com
name: thy-one
properties:
 baseUri: https://login.thycotic.com/
 clientId: xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
 clientSecret: xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
type: thycoticone
version: "0"

AWS Authentication Provider

To add an AWS account to act as an authentication provider:

  • dsv config auth-provider create --name <name> --type aws --aws-account-id <AWS account ID>

in which:

  • name is the friendly name used in VP-DV to reference this provider.
  • type is the authentication provider type; in this case, aws.
  • the property flag for AWS is --aws-account-id then include the account ID

To view the resulting addition to the config file, you would use:

dsv config auth-provider <name> read -e yaml where the example name we will use here is aws-dev

The readout would look similar to this:

Copy
created: "2019-11-12T18:34:49Z"
createdBy: users:thy-one:admin@company.com
id: xxxxxxxxxxxxxxxxxxxx
lastModified: "2020-05-18T03:58:15Z"
lastModifiedBy: users:thy-one:admin@company.com
name: aws-dev
properties:
  accountId: "xxxxxxxxxxxx"
type: aws
version: "0"

AWS User Example

When you create a User in AWS, remember that the username serves as a friendly name within VP-DV. It does not have to match the Identity Access Management (IAM) username, but the provider must match the provider name previously configured.

Copy
dsv user create --username test-admin --external-id arn:aws:iam::xxxxxxxxxxx:user/test-admin --provider aws-dev

After creating the User, modify the config to give that User access to the default administrator permission policy.

Adding a user to the admin policy is not security best practices. This is for example purposes only. Ideally, you would create a separate policy for this AWS user with restricted access. For details on limiting access through policies, see the Policy section.

Copy
dsv config edit -e yaml

Add test-admin as a User subject to the Default Admin Policy. Third party accounts must be prefixed with the provider name; in this case, the fully qualified username would be aws-dev:test-admin.

Copy
<snip>
- actions:
 - <.*>
 conditions: {}
 description: Default Admin Policy
 effect: allow
 id: xxxxxxxxxxxxxxxxxxxx
 meta: null
 resources:
 - <.*>
 subjects:
 - users:<aws-dev:test-admin|admin@company.com>
<snip>

Next, on a machine with the AWS CLI installed and configured with an AWS IAM user, download the DVS CLI executable appropriate to the OS of the machine, and initialize the CLI:

Copy
dsv init

When prompted for the authorization type, choose AWS IAM (federated).

Copy
Please enter auth type:
       (1) Password (local user)(default)
       (2) Client Credential
       (3) #{ThycoticOne}# (federated)
       (4) AWS IAM (federated)
       (5) Azure (federated)
       (6) GCP (federated)
       (7) OIDC (federated)

VP-DV will prompt for the specific AWS profile to use if you are authenticating using a non-default AWS profile.

Please enter aws profile for federated aws auth (optional, default:default)

Read an existing Secret to verify you can authenticate to VP-DV and access data.

Copy
dsv secret read --path <path to secret>

AWS Role Example

This example assumes that you:

  • have your own CLI configured locally with an admin account
  • created an IAM Role in the AWS Console
  • launched an EC2 instance using the IAM Role
  • downloaded the CLI onto the EC2 instance

Create a corresponding Role in VP-DV with the external-id of the IAM Role's ARN.

Copy
dsv role create --name test-role --external-id arn:aws:iam::xxxxxxxxxxx:role/testlogin --provider aws-dev

You should see a result similar to this:

Copy
{
"description": "",
"externalId": "arn:aws:iam::xxxxxxxxxxx:role/testlogin",
"name": "test-role",
"provider": "aws-dev"
}

Add the Role aws-dev:test-role to the Default Admin Policy in your vault config to grant the new Role admin access.

Adding a role to the admin policy is not security best practices. This is for example purposes only. Ideally, you would create a separate policy for this AWS role with restricted access. For details on limiting access through policies, see the Policy section.

Use the command dsv config edit -e yaml

Copy
<snip>
- actions:
 - <.*>
 conditions: {}
 description: Default Admin Policy
 effect: allow
 id: bgn8gjei66jc7148d9i0
 meta: null
 resources:
 - <.*>
 subjects:
 - users:<aws-dev:test-admin|admin@company.com>
 - roles:<aws-dev:test-role>
<snip>

On the EC2 instance, configure the CLI by running dsv init and choosing AWS IAM as the authentication type.

Once configured, ensure you can read an existing Secret to verify the EC2 instance is able to authenticate and access data.

Copy
dsv secret read --path <path to secret>
